บริการสอบเทียบเครื่องมือวัดด้าน Electrical / Frequency

Electrical

บริษัทมิราเคิลฯ ให้บริการสอบเทียบเครื่องมือวัดด้าน Electrical / Frequency

โดยสามารถจำแนกเป็นสถานภาพห้องปฏิบัติการ และชนิดเครื่องมือวัดดังนี้

In - Lab (ห้องปฎิบัติการ)
On - Site (นอกสถานที่)

	รายการสอบเทียบ (Parameter)	ช่วงการวัด (Measuring range)
Electrical Frequency	Temperature Indicator, RTD	-50	800	C
	Temperature Indicator, TC	-50	1400	C
	Temperature Indicator, Type TC K, E, J, N	-50	1200	C
	Temperature Indicator, Type TC R, S	0	1400	C
	Temperature Indicator, Type TC T	0	400	C

	Temperature Recorder, RTD	-50	800	C
	Temperature Recorder, TC	-50	1400	C
	Temperature Recorder, Type TC K, E, J, N	-50	1200	C
	Temperature Recorder, Type TC R, S	0	1400	C
	Temperature Recorder, Type TC T	0	400	C

	Temperature Transmitter	-50	1400	C

	Indicator	0	20	mA
		0	10	V
		0	100	%
		0	500000	l/h

	Controller	0	20	mA
		0	10	V
		0	100	%

	Recorder	0	20	mA
		0	10	V
		0	100	%

	Control Valve	0	20	mA
		0	10	V
		0	100	%

	Multifunction Process Calibrator	0	100	%

	Level Transmitter	-10000	20000	mm
		0	100	%Range

	Analog Multimeter (all range)	0	100	%Range
	Digital Multimeter (all range)	0	100	%Range

	DC Voltmeter	0	1000	V
	AC Voltmeter	0.001	1000	V

	AC Voltage Tester	0	150	kV

	Dry type AC voltage withstand test set	0	150	kV

	AC Ammeter	0.000029	20	A

	Earth Tester	0	100	%Range

	Ohm Meter	0	1100	MOhm

	Insulation Tester	0	1100	MOhm

	Capacitance Meter	0.00019	110000	uF

	Frequency Meter	0.01	2000	Hz

	LCR Hi Tester	0	100000	Hz

	Automatic Transformer Tester	0	200000	Hz

	Current Transformer Tester	0	120	%Range

	Clamp Meter (all range)	0	100	%Range
	Clamp Meter (DC Current)	0	1000	A
	Clamp Meter (AC Current)	0.000029	1000	A

	Power Meter 1 Phase	0	1000	V

	Impulse Winding Tester	0	5000	V

	Power Meter 1 Phase	0	1000	V
	Power Meter 3 Phase	0	520	V
	Power Meter 3 Phase	0	520	V

	Phase Rotation Tester	0	100	%Range

	Solar PV Tester and I-V Curve Tracer	0	100	%Range

	DC Power Supply	0	100	%Range

	Super Megohmmeter	0	10000	MOhm

	Milliohm Hi Tester	0	20	MOhm

	Pyranometer	0	1300	W/m2

	Laser Power Meter	0	100	W

	Shunt	0	20	A

	DC Current Generator	0	2.1	A
	DC Voltage Generator	0	1000	V
	AC Current Generator	0	2	A
	AC Voltage Generator	0	750	V
	AC Current & AC Voltage Generator	0	100	%Range

	Surface Resister Meter	0	1000	MOhm
	Contact Resister Tester	0	1000	uOhm

	Resistance Generator	0	1100	MOhm

	Decade Resistor	0	1100	MOhm
	Shunt Resistor	0	1100	MOhm

	Frequency Generator	0.01	2000	MHz
	Frequency 6GHz Counter	0	100	%Range

	Temperature Source, all range	-250	1767	C
	Temperature Source, RTD	-190	600	C
	Temperature Source, Type TC K, E, J, N	-250	1372	C
	Temperature Source, Type TC R, S	0	1767	C
	Temperature Source, Type TC B	600	1820	C
	Temperature Source, Type TC T	-200	1300	C

	Current Probe	0	100	A

	Data Acquisition (USB Multifunction I/O Device)	0	10	V

	Stroboscope	6	100000	rpm

	Tachometer, Photo	6	199980	rpm
	Tachometer, Contact	0.5	20000	rpm
	Tachometer, Photo-Contact	6	199980	rpm
	Tachometer, Photo-Surface	6	199980	rpm
	Tachometer, Contact-Surface	6	199980	rpm
	Tachometer, Photo-Contact-Surface	6	199980	rpm
	Tachometer, Photo-Contact-Surface	6	3657.6	m/min

	Centrifuge	0	20000	rpm

	Rotator with timer	0	1000	rpm

	Optical Light Gates	0	120	km/h

	Stop Watch	2	32768	Hz
	Stop Watch	0	21600	s
	Timer	0	9600	s
	Timer	0	9600	s
	Watch	0	7200	s

	Flow Meter	0	10000000	l h-1
		0	10000000	kg hr-1

	Density Transmitter	0	2000	kg m-3

	Conductivity Meter	0	1.5	MOhm
		0.73	50.59	uS/cm

	Magnet Bar	0	15000	Gauss
	AC/DC Magnetic Field Meter	0	10000	Gauss

	Tesla Meter	0	3000	mT
		0	12000	Gauss

	Wood Moisture Meter (Pine)ไม้สน	11.8	27.2	%MC
	Wood Moisture Meter (Spruce)ไม้สปรูช	12.1	29.8	%MC
	Wood Moisture Meter (Oak)ไม้โอ๊ค	10.1	23	%MC

	Spectrophotometer (Wavelength)	0	1000	nm
	Spectrophotometer (full functions)	0	1000	nm
	Spectrophotometer (Wavelength & Photometric)	0	1000	nm

	Radiation Survey Meter	0	350	uSv/h

	Static Charge Meter	0	30	kV

	Vibration Meter (max 50 mm/s)	5	50	m s-2
	Vibration Meter	2	30	m s-2

	AC/DC/IR Hipot Tester	0	110000	kV

	Motor and Phase Rotation Indicator	0	100	%Range

	Earth Continual Tester	0	100	%

	Insulation Tester (0-10 kVolt) 0 to 1 Tohm	0	1	Tohm

	Displacement Transducer	0	100	mm

	PD Calibrator	0	400	cP

	3 Phase Energy Meter	0	100	%

	Shear Accelerometer	0	100	%Range

	Chlorine Portable Photometer	0	2	A

	Precise Color Reader	0	100	%

	Nav/Comm Flight Line Test Set	0	100	%

	Transponder/DME/TCAS Flight Line Test Set	0	100	%

	Oil Tester	0	60	kV

	Oscilloscope	0	100	%Range
	Signal Generator	0	100	%Range
	Attenuator	0	100	%Range

	รายการสอบเทียบ (Parameter)	ช่วงการวัด (Measuring range)
Electrical Frequency	Temperature Indicator, RTD	-50	800	C
	Temperature Indicator, TC	-50	1400	C
	Temperature Indicator, Type TC K, E, J, N	-50	1200	C
	Temperature Indicator, Type TC R, S	0	1400	C
	Temperature Indicator, Type TC T	0	400	C

	Temperature Recorder, RTD	-50	800	C
	Temperature Recorder, TC	-50	1400	C
	Temperature Recorder, Type TC K, E, J, N	-50	1200	C
	Temperature Recorder, Type TC R, S	0	1400	C
	Temperature Recorder, Type TC T	0	400	C

	Temperature Transmitter	-50	1400	C

	Indicator	0	20	mA
		0	10	V
		0	100	%
		0	500000	l/h

	Controller	0	20	mA
		0	10	V
		0	100	%

	Recorder	0	20	mA
		0	10	V
		0	100	%

	Control Valve	0	20	mA
		0	10	V
		0	100	%

	Level Transmitter	-10000	20000	mm
		0	100	%Range

	Analog Multimeter (all range)	0	100	%Range
	Digital Multimeter (all range)	0	100	%Range

	DC Voltmeter	0	1000	V
	AC Voltmeter	0.001	1000	V

	AC Voltage Tester	0	150	kV

	Dry type AC voltage withstand test set	0	150	kV

	AC Ammeter	0.000029	20	A

	Earth Tester	0	100	%Range

	Ohm Meter	0	1100	MOhm

	Insulation Tester	0	1100	MOhm

	Capacitance Meter	0.00019	110000	uF

	Frequency Meter	0.01	2000	Hz

	LCR Hi Tester	0	100000	Hz

	Automatic Transformer Tester	0	200000	Hz

	Current Transformer Tester	0	120	%Range

	Clamp Meter (all range)	0	100	%Range
	Clamp Meter (DC Current)	0	1000	A
	Clamp Meter (AC Current)	0.000029	1000	A

	Power Meter 1 Phase	0	300	V

	Impulse Winding Tester	0	5000	V

	Power Meter 1 Phase	0	300	V
	Power Meter 3 Phase	0	520	V
	Power Meter 3 Phase	0	520	V

	DC Power Supply	0	100	%Range

	Milliohm Hi Tester	0	20	MOhm

	Contact Resister Tester	0	1000	uOhm

	DC Current Generator	0	2.1	A
	DC Voltage Generator	0	1000	V
	AC Current Generator	0	2	A
	AC Voltage Generator	0	750	V
	AC Current & AC Voltage Generator	0	100	%Range

	Frequency Generator	0.01	2000	MHz
	Resistance Generator	0	1100	MOhm

	Decade Resistor	0	1100	MOhm
	Shunt Resistor	0	1100	MOhm

	Current Probe	0	100	A

	Data Acquisition (USB Multifunction I/O Device)	0	10	V

	Temperature Source, all range	-250	1767	C
	Temperature Source, RTD	-190	600	C
	Temperature Source, Type TC K, E, J, N	-250	1372	C
	Temperature Source, Type TC R, S	0	1767	C
	Temperature Source, Type TC B	600	1820	C
	Temperature Source, Type TC T	-200	1300	C

	Centrifuge	0	20000	rpm

	Rotator with timer	0	1000	rpm
	Speed Meter	0	500	m/min
	Speed Counter	0	500	m/min

	Stop Watch	0	9600	s
	Timer	0	9600	s

	Timing Interval for Scada	0	3600	s

	Flow Meter	0	10000000	l h-1
		0	10000000	kg hr-1

	Density Transmitter	0	2000	kg m-3

	Conductivity Meter	0.73	50.59	uS/cm

	Vibration Meter	2	30	m s-2

	Magnet Bar	0	15000	Gauss

	Spectrophotometer (Wavelength)	0	1000	nm
	Spectrophotometer (full functions)	0	1000	nm

	Microplate Reader BioTek Model Elx800	0	100	%Range

	Motor and Phase Rotation Indicator	0	100	%Range

	Earth Continual Tester	0	100	%

	Insulation Tester (0-10 kVolt) 0 to 1 Tohm	0	1	Tohm

	Displacement Transducer	0	100	mm

	Transponder/DME/TCAS Flight Line Test Set	0	100	%

	Oil Tester	0	60	kV

	Oscilloscope	0	100	%Range

	Loop Test	0	100	%
